ATEN VB100 VGA BOOSTER 1280 x 1024 70 METER
Deskripsi:
The VB100 VGA Booster amplifies the VGA signal from a source device and transmits it to a display up to 70 meters away. The VGA booster extends the display distance without any signal loss; to bring you a crystal clear video display at a longer distance. The VB100 is built with a compact housing design for easy installation and manual gain control to improve image quality at different distances. The VB100 can be powered from the VGA source and has a built-in LED indicator for power. The VB100 supports hotplugging and requires no software forinstallation, making it an easy, compact, and affordable solution to extend your VGA display.
* features
Long distance transmission – up to 70 m
Adjustable video compensation – manually adjust signal strength to compensate for distance
Superior video quality – up to 1920 x 1200 (30 m); 1280 x 1024 (70 m)
Supports VGA, XGA, SVGA, UXGA, WUXGA, and multisync monitors
Supports wide screen formats
Supports hot-plugging
Compact housing
LED indication of power status and source device
Plug-and-play – no software installation required.
* support
Video Input
Interfaces 1 x HDB-15 Female (Blue)
Impedance 75 Ώ
Video Output
Interfaces 1 x HDB-15 Female (Blue)
Impedance 75 Ώ
Video
Max. Bandwidth 300 MHz
Max. Resolutions / Distance Up to 1920 x 1200@30m; 1280 x 1024@70m
Connectors
Power 1 x DC Jack
Power Consumption DC5V:0.63W:3BTU
Environmental
Operating Temperature 0 - 50°C
Storage Temperature -20 - 60°C
Humidity 0 - 80% RH, Non-Condensing
Physical Properties
Housing Metal
Weight 0.06 kg ( 0.13 lb )
Dimensions (L x W x H) 3.53 x 6.88 x 2.06 cm
(1.39 x 2.71 x 0.81 in.)
* features
Long distance transmission – up to 70 m
Adjustable video compensation – manually adjust signal strength to compensate for distance
Superior video quality – up to 1920 x 1200 (30 m); 1280 x 1024 (70 m)
Supports VGA, XGA, SVGA, UXGA, WUXGA, and multisync monitors
Supports wide screen formats
Supports hot-plugging
Compact housing
LED indication of power status and source device
Plug-and-play – no software installation required.
* support
Video Input
Interfaces 1 x HDB-15 Female (Blue)
Impedance 75 Ώ
Video Output
Interfaces 1 x HDB-15 Female (Blue)
Impedance 75 Ώ
Video
Max. Bandwidth 300 MHz
Max. Resolutions / Distance Up to 1920 x 1200@30m; 1280 x 1024@70m
Connectors
Power 1 x DC Jack
Power Consumption DC5V:0.63W:3BTU
Environmental
Operating Temperature 0 - 50°C
Storage Temperature -20 - 60°C
Humidity 0 - 80% RH, Non-Condensing
Physical Properties
Housing Metal
Weight 0.06 kg ( 0.13 lb )
Dimensions (L x W x H) 3.53 x 6.88 x 2.06 cm
(1.39 x 2.71 x 0.81 in.)
